Select Series™ 3mm, High-Throughput NMR Tubes, 25 Pack

• 3mm
• High-Throughput
• 8 Inch (203mm)
• Ships with Economy Cap. NorLoc™ Caps Sold Separately.

Our “Select Series™” NMR tubes are manufactured out of ASTM Type 1 Class A glass, commonly referred to as Pyrex® 7740 (Corning), Duran® (Schott Glass), or Kimax® KG-33 (Kimble) glass.

Key properties that make this glass type desirable for NMR are its high degree of thermal shock resistance and low expansion coefficient. This allows for a greater margin of safety from breakage when used in variable temperature applications and freeze/thaw cycling, or under any other application where large temperature variations are required in the experiment.

Each NMR tube is checked for concentricity and camber specifications utilizing the latest computer technology.

Select Series™ 3mm, Ultra-Precision NMR Tubes, 5 Pack

• 3mm
• 200MHz
• 8 Inch (203mm)
• Ships with Economy Cap. NorLoc™ Caps Sold Separately.

Our “Select Series™” NMR tubes are manufactured out of ASTM Type 1 Class A glass, commonly referred to as Pyrex® 7740 (Corning), Duran® (Schott Glass), or Kimax® KG-33 (Kimble) glass.

Key properties that make this glass type desirable for NMR are its high degree of thermal shock resistance and low expansion coefficient. This allows for a greater margin of safety from breakage when used in variable temperature applications and freeze/thaw cycling, or under any other application where large temperature variations are required in the experiment.

Each NMR tube is checked for concentricity and camber specifications utilizing the latest computer technology.

Standard Series™ High-Throughput NMR Tubes, 100 Pack

• 5mm
• High-Throughput
• 7 Inch (178mm)
• For Routine NMR

Our “Standard Series™” NMR tubes are manufactured out of ASTM Type 1 Class B glass, commonly referred to as N-51A. Applications that are suited for using this type of glass are routine NMR where samples are run under room temperatures with no thermal gradients. It is therefore not recommended to fuse this glass with standard vacuum manifolds and the like, since these are generally made out of Type 1 Class A glass. Each NMR tube is checked for concentricity and camber specifications utilizing the latest computer technology.

Standard Series™ Precision NMR Tubes, 5 Pack

• 10mm
• 300MHz
• 8 Inch (203mm)
• For Routine NMR

Our “Standard Series™” NMR tubes are manufactured out of ASTM Type 1 Class B glass, commonly referred to as N-51A. Applications that are suited for using this type of glass are routine NMR where samples are run under room temperatures with no thermal gradients. It is therefore not recommended to fuse this glass with standard vacuum manifolds and the like, since these are generally made out of Type 1 Class A glass. Each NMR tube is checked for concentricity and camber specifications utilizing the latest computer technology.

Economy NMR Tube Caps, 100 Pack
Our economy NMR tube caps are now available in 12 different colors for better solvent labeling capabilities.

• 5mm
• Red
• Ethylene-Vinyl Acetate

Amberized Standard Series NMR Sample Tubes, 1 Pack

• 5mm
• 7" (178mm)
• 500MHz
• For Routine NMR

Available with ULTRA-THIN wall NMR Tubes.

Pictured with optional NorLoc™ Cap. Amberized NMR tubes ship with economy caps.

Coaxial Inserts for NMR Sample Tube for Bruker Spectrometers
4mm Quartz Tube W/50mm STEM. Includes one S-5-400-7 NMR tube to be used with the Coaxial Insert.

50mm Stem OD is 3mm, Stem Sample Capacity is 175μL

Please note: we cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Sample Vault Series™ NMR Tubes, 96 Pack

• 3mm
• Up to 700MHz
• 178mm
• Packed in Lots of 96
• Ships with Closed Port Sample Vault Caps

Sample Vault™ Series NMR tubes with Sample Vault™ caps (U.S. Patent No. 8,054,080), are engineered for a new generation of high-throughput lab automation systems, including the Bruker SampleJet.

Our patented design incorporates a white band positioned on the NMR tube that aligns with the base of the cap, indicating a properly locked position. Together, our Sample Vault™ caps and Sample Vault™ tubes form an integrated closure system for fail-safe delivery of your sample into the magnet.

5mm Valved NMR Tubes for Intermediate Pressure, 1 Pack

• 5mm
• 500MHz
• 7" (178mm)
• Thin Wall

This valve incorporates an advanced seal design that is superior to alternative valves currently available from other manufacturers. A fluoroelastomer o-ring imparts resilience and a high degree of chemical resistance. A PTFE sheath, forming the primary seal, completely covers the fluoroelastomer o-ring, creating the ultimate barrier against aggressive, reactive substances while providing a totally inert surface.

These pressure tubes facilitate experiments requiring conditions such as pressurized inert atmosphere blanketing, addition of reactive gaseous reagents under pressure, containment of low boiling point solvents or samples at elevated temperatures, and so on.

We recommend that the maximum operating pressure should be limited to 600 kPa (6 bar, 87 psi) when using a thin wall pressure tube, up to 1200 kPa (12 bar, 175 psi) if using a heavy wall pressure tube. (Please see accompanying table for complete details).

Secure Series™ NMR Tubes 5 Pack

• 5mm
• 400MHz
• 7 Inch (178mm)
• Includes “Norloc™ with Security Band” Caps
• A patented proprietary surface treatment with a unique textured surface ensures precise and positive retention in Bruker, Agilent/Varian, and Jeol spinner turbines.

The Secure 33 Series™ NMR tubes are made from ASTM Type I Class A borosilicate glass ("low expansion" borosilicate glass such as Corning Pyrex® 7740 or equivalent) and match the properties of the Select Series™ NMR tubes from Norell®.

Secure Series™ NMR tubes feature several patented design elements that add a superior level of sample containment and isolation, safeguarding the integrity of precious or critical NMR samples and assuring secure retention of the NMR tube in the spinner turbine.

Secure Series™ NMR Tubes ship with our patented NorLoc Caps™ featuring a Security Band™ that engages and locks into the NorLoc II Security Cap™, securely joining the cap to the NMR tube.
